HX-CS-230/14L Manufacturer Customized Box Drawing Facial Tissue Packing Machine
Product Description:
The jumbo rolls which have been slit into the desired width are cut by the slitting cylinders, and then inter-folded into inter-overlapped rectangular facial tissue sheets. This machine adopts independent servo motor drive, automatic sipped, electrostatic treatment, security system, automatic cutting and stop, automatic tension adjustment, base paper power struggle, automatic marking functions. It has the features of high speed, nice folding and easy operation.
Function and Features:
1. Each unit is driven by an independent servo, which can adapt to different base paper expansion ratios.
2. The whole machine is a wall plate rack structure, and the machine runs fast and has excellent stability.
3. Pneumatic jumbo roll loading on the paper return shelf, flexible speed adjustment, and can automatically adjust different paper tension
4. Equipped with Roots type vacuum pump for large inspiratory capacity and stable running of the machine.
5. Insertion point counting, simple and practical.
6. Equipped with steel to steel edge embossing device to keep the double plies together.
7. The machine would stop when the paper got broken to avoid waste caused by no paper or broken paper.
8. Adopt back and forth jog switch for towing the base paper, which is easy and safe to operate.
Main Technical Parameters:
| Production speed | (60-100)m/min | ||||
| Product unfold size (mm) | 180 (long) x130-210 (wide adjustable) | ||||
| 190 (long) x130-210 (wide adjustable) | |||||
| 200 (long) x130-210 (wide adjustable) | |||||
| Folding products size (mm) | 90 (long) x130-210 (wide adjustable) | ||||
| 95 (long) x130-210 (wide adjustable) | |||||
| 100 (long) x130-210 (wide adjustable) | |||||
| Maximum cutting base paper size | 5L:1050mm | 6L:1260mm | 7L:1400mm | 9L:1750mm | 10L:2000mm |
| Roots Vacuum pump | 5L:15KW | 6L:15KW | 7L:18.5KW | 9L:22KW | 10L:30KW |
| Machine dimension (m) | Depends on Machine Model | ||||
| Equipment weight(kg) | Depends on the size and configure | ||||
Our Advantages:
| Experience | Establish in the middle of 1990s, more than 25 years’ experience. |
| Manufacturer | We are 100% factory. |
| One-stop Service | Your One-Stop Solution Supplier, from design, production to shipping. |
| OEM&ODM | OEM or ODM is available. |
| Fast Production | We have a professional design team and a big range of machines. |
| Quality Control | We strictly follow quality management system to insure product quality. |
| Production Ability | Own the factory building and machines to make price competitive. |
Final Products Display:
| Toilet Paper | Toilet Paper |
| Toilet Paper with Core | |
| Toilet Paper without Core | |
| Facial Tissue | Soft Facial Tissue |
| Box Facial Tissue | |
| Pocket Facial Tissue | |
| Kitchen Towel | Napkin Paper |
| Printing Napkin | |
| Kitchen Towel |
Packing & Shipping:
| Packing | Wooden pallet according to specific size of each equipment, we twine thick plastic coating for each machine. |
| Packing Details | Tight the equipment in the pallet without space to ensure no rubbing during the transportation. |
| Shipping | Sea transportation or train. |
