Manufacturer Direct HX-CS-220/14L Box Drawing Facial Tissue Making Machine
The jumbo rolls which have been slit into the desired width are cut by the slitting cylinders, and then inter-folded into inter-overlapped rectangular facial tissue sheets. This machine adopts independent servo motor drive, automatic sipped, electrostatic treatment, security system, automatic cutting and stop, automatic tension adjustment, base paper power struggle, automatic marking functions. It has the features of high speed, nice folding and easy operation.
Function and Features:
1. Each unit is driven by an independent servo, which can adapt to different base paper expansion ratios.
2. The whole machine is a wall plate rack structure, and the machine runs fast and has excellent stability.
3. Pneumatic jumbo roll loading on the paper return shelf, flexible speed adjustment, and can automatically adjust different paper tension
4. Equipped with Roots type vacuum pump for large inspiratory capacity and stable running of the machine.
5. Insertion point counting, simple and practical.
6. Equipped with steel to steel edge embossing device to keep the double plies together.
7. The machine would stop when the paper got broken to avoid waste caused by no paper or broken paper.
8. Adopt back and forth jog switch for towing the base paper, which is easy and safe to operate.
Main Technical Parameters:
Product unfold size (mm)
180 (long) x130-210 (wide adjustable)
190 (long) x130-210 (wide adjustable)
200 (long) x130-210 (wide adjustable)
Folding products size (mm)
90 (long) x130-210 (wide adjustable)
95 (long) x130-210 (wide adjustable)
100 (long) x130-210 (wide adjustable)
Maximum cutting base paper size
Roots Vacuum pump
Machine dimension (m)
Depends on Machine Model
Depends on the size and configure
Establish in the middle of 1990s, more than 25 years’ experience.
We are 100% factory.
Your One-Stop Solution Supplier, from design, production to shipping.
OEM or ODM is available.
We have a professional design team and a big range of machines.
We strictly follow quality management system to insure product quality.
Own the factory building and machines to make price competitive.
Final Products Display:
Toilet Paper with Core
Toilet Paper without Core
Soft Facial Tissue
Box Facial Tissue
Pocket Facial Tissue
Packing & Shipping:
Wooden pallet according to specific size of each equipment, we twine thick plastic coating for each machine.
Tight the equipment in the pallet without space to ensure no rubbing during the transportation.
